Optimize Efficiency with Logic Analyzer Software

Keysight logic analyzer software allows you to gain quick insight into your digital system. These software applications provide a wide range of additional capabilities including shortening setup time and customizing measurement displays.

Our pioneering FPGA solutions save you hours of debug time by simplifying access to internal FPGA signals and dramatically reducing the time required to setup logic analyzer measurements.

For more information about our logic analyzer software, please visit Keysight Logic Analyzer Software.

Find The Right Logic Analyzer Software For You

これらの製品のいずれかをすでにお持ちですか？ テクニカル・サポートを見る
前
B4641A
B4641A プロトコル開発キット
スタート価格:
プロトコル開発キット
B4661A
B4661A ロジック・アナライザ用メモリ解析ソフトウェア
スタート価格:
DDR3/DDR4/LPDDR2/LPDDR3/LPDDR4システムのデバッグ／検証用のB4661A メモリ解析ソフトウェアとキーサイトのロジック・アナライザを使用すれば、より短時間で詳細に解析できます。
B4601C
B4601C シリアル・パラレル解析パッケージ
スタート価格:
シリアル・データの表示と解析が簡単に行えます。
全モデルの表示と比較
次へ
全モデルの表示と比較

Protect Your Innovation Investment

KeysightCare サポートプラン

最新のアプリケーションソフトウェアとファームウェア、およびエキスパートによるテクニカルサポートを最短時間で提供することで、イノベーションを迅速に進めることができます。

ソフトウェア ライセンス

条件や種類を選択して予算管理が可能で、柔軟性のあるサポートを提供。

ソフトウェアマネージャー

ご利用のキーサイトソフトウェアの管理、ライセンスの請求、最新アップデートヘのアクセス。

Featured Resources for Logic Analyzer Software

Application Notes 2017.12.01

Solve Debugging Problems with Logic Analyzer

Read 8 useful tips on using use logic analyzers to effectively solve debug problems to quickly achieve reliable measurement.

2017.12.01

Application Notes 2026.02.28

Evaluating Logic Analyzers Objectively

The considerations outlined in this application note are intended to speed your selection process and help you avoid common pitfalls.

2026.02.28

Data Sheets 2017.12.05

Frequently Asked Questions B4655A FPGA Dynamic Probe for Xilinx

Keysight's FPGA dynamic probe for Xilinx FPGA’s provides greater real-time measurement productivity for logic-analysis based validation of FPGAs and the surrounding system. The tool features: increased visibility, faster probing changes, and automatic setup of the logic analyzer.

2017.12.05

Data Sheets 2017.12.01

Frequently Asked Questions B4656A FPGA Dynamic Probe for Altera

Keysight's FPGA dynamic probe for Altera’s FPGA’s provides greater real-time measurement productivity for logic-analysis based validation of FPGAs and the surrounding system. The tool features: increased visibility and faster probing changes.

2017.12.01

User Manuals 2009.09.02

EPM Firmware Revision Information

EPM: E4418/19B Power Meter Firmware multiple revisions information, including power meter manual and feature for different power meter series.

2009.09.02

Data Sheets 2024.12.02

B4655A FPGA Dynamic Probe for Xilinx

Collaborative development between Keysight and Xilinx have produced a faster and more effective way to use your logic analyzer to debug FPGAs and the surrounding system. The Keysight PFGA dynamic probe, used in conjunction with an Keysight logic analyzer, provides the most effective solution for simple through complex debugging.

2024.12.02

Data Sheets 2017.12.02

B4656A FPGA Dynamic Probe for Altera

FPGA Dynamic Probe for Altera simplifies the debug of digital systems incorporating Altera FPGAs. This data sheet describes the features and corresponding benefits of the product. It includes a quick tour of the product’s operation to give you a feel for exactly how it works and what you can expect from its operation in conjunction with your Altera Quartus design tools and your logic analyzer. Implementation details, such as supported logic analyzers and software versions, are also included in this document.

2017.12.02

データシート 2015.06.25

Keysight U4154A AXIe準拠ロジック・アナライザ・モジュール

The Keysight U4154A AXIe-based logic analyzer provides reliable data capture on signals up to 4 Gb/s with eye openings as small as 100 ps by 100 mV

2015.06.25

すべてのリソースを表示

Frequently Asked Questions - Logic Analyzer Software

Logic analyzer software is any application that runs on logic analyzers. It is used to capture, view, and analyze digital signals. It allows engineers and technicians to understand digital system behavior, essential for debugging, testing, and validating digital communication systems at the protocol level. Logic analyzer software can be specialized to help analyze specific digital protocols, such as DDR memory systems.

Common debugging problems that can be identified and solved with logic analyzer software are signal integrity issues, timing issues, inadequate sample rates, and protocol decoding issues. Some of these issues can be solved with a mixed signal oscilloscope, many of which can detect signal integrity issues at the physical layer and have digital channels for examining timing issues. However, for applications with many channels, a logic analyzer is required.

To test double data rate (DDR) memory, you will need logic analyzer software that supports DDR decoding and analysis. The Keysight B4661A memory analysis software enables logic analyzers to decode traffic for DDR3, DDR4, DDR5, and other memory protocols.

Hardware requirements vary for Keysight logic analyzer software, mainly due to bandwidth and channel requirements. Please refer to the datasheet for the logic analyzer software you choose to verify if a software application can run on your hardware.
