Highlights

Built to address high-bandwidth applications like 5G carrier aggregation and amplifier test, 802.11ax/be, satellite, radar, and electronic warfare (EW), Keysight’s N9032B PXA X-Series signal analyzer delivers the widest analysis bandwidth in its class. Our measurement software applications help you optimize your most complex designs and stay up to date on the latest requirements. Get the best swept displayed average noise level (DANL), error vector magnitude (EVM) performance, and sensitivity in a compact 4U-high form factor.

  • Ready-to-use PathWave X-Series measurement applications and PathWave 89600 vector signal analysis software to ensure standards compliance and more
  • Up to 2 GHz bandwidth option available on all models
  • Superior spur searching speed with industry-best swept DANL
  • Industry-best EVM residuals and sensitivity
  • Drop-in replacement for rack-mounted spectrum analyzers and a compact 4U-high form factor
  • Order-of-magnitude improvement in accuracy with the U9361 RCal receiver calibrator

Test Application Software

Keysight's PathWave X-Series measurement applications address changing measurement requirements for the latest communications standards. Get ready-to-use measurements for cellular communication, wireless connectivity, EW, radar, satellite communications, and general-purpose applications.

The 89600 PathWave VSA software is a comprehensive set of tools for demodulation and vector signal analysis. With support for more than 75 signal standards and modulation types, these tools enable you to explore virtually every facet of a signal and optimize your most advanced designs.

N9032B Spectrum analyzer (N9032B signal analyzer) image

Principais especificações

Frequência
55 GHz
DANL @1 GHz
-174 dBm
Análise máxima de largura de banda
2 GHz
Largura de banda máxima em tempo real
Up to 2 GHz
Ruído de fase @1 GHz (10 kHz offset)
-136 dBc/Hz
Type
Signal Analyzer
Frequência
DANL @1 GHz
Análise máxima de largura de banda
Largura de banda máxima em tempo real
Ruído de fase @1 GHz (10 kHz offset)
Type
55 GHz
-174 dBm
2 GHz
Up to 2 GHz
-136 dBc/Hz
Signal Analyzer
Visualizar mais
Opções de largura de band:
1 GHz
1.5 GHz
2 GHz
DANL @1 GHz:
-174 dBm
Form Factor:
N/A
Frequência:
55 GHz
Opções de frequência:
8.4 GHz
13.6 GHz
26.5 GHz
44 GHz
50 GHz
55 GHz
Mixers to 1.1 THz
Height:
4U
Análise máxima de largura de banda:
2 GHz
Frequência máxima:
55 GHz
Largura de banda máxima em tempo real:
Up to 2 GHz
Precisão da amplitude geral:
±0.20 dB
Nível de desempenho:
◆◆◆◆◆◇
Ruído de fase @1 GHz (10 kHz offset):
-136 dBc/Hz
TOI @1 GHz (3rd Order Intercept):
+22 dBm
Type:
Signal Analyzer

See the Power of Our New Group Delay Software Application Yourself

Take a Tour

  • Start immediately
  • Self-serve? Yes
  • Experience duration: 3 mins

Request a Live Demo

  • Start in < 2 days
  • Self-serve? No
  • Experience duration: 30 mins

Request a Free Trial

  • Start immediately
  • Self-serve? Yes
  • Experience duration: 30 days

Wireless & Cellular Communications

Wider analysis bandwidth is becoming increasingly important to characterize the next generation of wireless and communications devices. Now you can have an ideal compact solution with superior performance to satisfy your wide bandwidth requirements at low frequencies for device characterization.

The N9032B PXA X-Series signal analyzer provides up to 2 GHz analysis bandwidth on all models, including the cost-effective 8.4 GHz model. PathWave measurement application software enables you to quickly and easily characterize 802.11be and 5G NR devices. The powerful new CPU enables 40% faster time to actionable insights. The N9032B PXA gives you more ways to optimize DANL and dynamic range with its unique signal path front-end. ​

cellular communication image

Satellite Communications

Today's satellite communication systems require a more sophisticated approach to characterize wideband components — one that supports wide analysis bandwidth even at low range frequencies. Complex test setups introduce measurement errors and extend measurement time.

With a corrected analysis bandwidth of up to 2 GHz and powerful PathWave Vector Signal Analysis (89600 VSA) software, the N9032B PXA offers the best swept DANL and EVM in its class. RCal increases accuracy without the need for complex system calibration.

EMSO and Electronic Warfare

Testing newer, sophisticated, high-performance EMSO requires much lower DANL for faster spur search than before. The N9032B PXA with PathWave Vector Signal Analysis (89600 VSA) software provides outstanding DANL, faster spur search, and extended bandwidth, reducing test time.

Thanks to the exceptional dynamic range, you can visualize wideband signals and agile signals up to 2 GHz bandwidth. With the 4U-high compact design, you no longer have to sacrifice performance for lab space.

EMSO and electronic warfare image
signal analysis solution set up

Do More with your Signal Analyzer

Reach even higher levels of measurement accuracy with the following:

N9032B Spectrum analyzer (N9032B signal analyzer) image
