FlexDCA Sampling Oscilloscope Software
The FlexDCA Sampling Oscilloscope Software N1010A runs Keysight’s digital communication analyzer (DCA) of sampling oscilloscopes with a new user interface.
The FlexDCA Sampling Oscilloscope Software N1010A runs Keysight’s digital communication analyzer (DCA) of sampling oscilloscopes with a new user interface.
FlexDCA Sampling Oscilloscope Software
N1010A
The FlexDCA Sampling Oscilloscope Software N1010A runs Keysight’s digital communication analyzer (DCA) of sampling oscilloscopes with a new user interface.
Keysight’s N1010A FlexDCA is the software that runs Keysight’s digital communication analyzer (DCA) family of sampling oscilloscopes (also known as equivalent-time oscilloscopes). A DCA is an instrument that helps visualize and analyze the analog properties of high-speed signals such as those used in wireline telecom and data center links.
FlexDCA is installed at the factory on DCA-X mainframes but can also be installed on a PC to control a DCA-M or remotely control a DCA-X.
- Powerful and flexible capability: Basic measurements are built in, and you can add packages as needed.
- Consistent results: Use in design to simulate and analyze signals, in the lab to characterize prototypes, and in production and support to operate equipment remotely.
In addition to the data acquisition and basic measurement capabilities the N1010A FlexDCA software provides, Keysight offers a large selection of software tools with powerful capabilities:
- N1010100A, research and development package for the FlexDCA sampling oscilloscope software: This package is intended for R&D engineers who want to characterize their designs and gain more insight into why a signal deviates from the expected performance. It includes FlexRT Advanced for optical measurements on UXR-Series Oscilloscopes.
- N1010200A, manufacturing package for the FlexDCA sampling oscilloscope software: This package focuses on cost of test in optical transceiver manufacturing applications with capabilities such as FlexEye that enhance measurement flexibility. It includes measurements such as TDECQ and FlexRT Basic for optical measurements on UXR-Series Oscilloscopes.
- N1010300A, signal integrity package for the FlexDCA sampling oscilloscope software: This package adds powerful tools to measure impedances, transfer characteristics, S-parameter calculations to the basic TDR / TDT measurements, and FlexPLL for phase-locked loop measurements.
- FlexOTO, FlexOTO software is designed for high optical lane count testing on 800G/1.6T and multi-channel applications to improve test efficiency and increase utilization of DCA-M hardware without compromising measurement integrity.
For a mapping of legacy FlexDCA feature-based options to each of the software packages available, refer to DCA Configuration Guide under N1010x00A Analysis Packages mapping table.
D902xHDMC Electrical Performance, Validation, and Compliance Test Software for HDMI Transmitter
Electrical Performance, Validation, and Compliance Test Software for HDMI Transmitter
Electrical Performance, Validation, and Compliance Test Software for HDMI Transmitter
D902xHDMC Electrical Performance, Validation, and Compliance Test Software for HDMI Transmitter
D9021HDMC
Electrical Performance, Validation, and Compliance Test Software for HDMI Transmitter
License-dependent test suites for HDMI transmitters:
- D9021HDMC license: HDMI 1.4, HDMI 2.1 TMDS (formerly HDMI 2.0), HDMI 2.1 Fixed Rate Link through 12 Gbps, and Direct Attach devices
- D9022HDMC license: HDMI 2.2 Fixed Rate Link at 16, 20, and 24 Gbps only
- Supports waveform storage for post-processing on scope or offline on a PC.
- Device capability entry using resolution and timing descriptors, video identifier codes (VIC) as well as FRL features
- Automated test sequencing for given test connection
- Full device automation using optional switch network
- Guided connection and instructions throughout the test process
- Test report including system, connection details, summary table, with hotlinks to ancillary test result data, and screen shots of the test measurements
- Tabular final results page with statistical analysis
The D902xHDMC software family provides an automated environment for validating and troubleshooting the electrical performance of HDMI transmitter designs. The common D9021HDMC application installer supports two license-controlled test suites: the D9021HDMC license enables TMDS and FRL testing through 12 Gbps, while the D9022HDMC license enables FRL testing at 16, 20, and 24 Gbps only. Both licenses are required to access both coverage ranges.
The D902xHDMC electrical performance validation and compliance software for HDMI transmitters provides a fast and easy way to verify and debug High-Definition Multimedia Interface (HDMI) designs for set-top boxes, digital video recorders, DVD players, and motherboard systems. D9022HDMC is supported on UXR-Series oscilloscopes, while D9021HDMC is supported on Infiniium V-, Z-, and UXR-Series oscilloscopes. The HDMI compliance test software automatically executes HDMI electrical checklist tests and presents the results in a comprehensive report. In addition to measurement data, the report provides margin analysis showing how closely the device meets each test limit.
This software supports post processing of waveforms to greatly improve productivity. Post processing can be done on the oscilloscope after waveforms have been acquired or on a PC with a licensed compliance application using Infiniium Offline D9010BSEO. Other required components for solution are: a test point adapter with HDMI plug (TPA-P), probe amplifiers and probe heads, high quality matched cables, and an EDID and SCDC controller device.
HDMI2.1 TMDS (formally HDMI2.0) HDMI2.1 FRL and HDMI2.2 FRL require single-ended connections for single-ended measurements as well as for TP2 differential measurements. Keysight probe and switching offerings include N7010A active termination adapters for the lowest cost connection or N7003A Infiniimode amplifiers with internal switches to enable one connection full FRL testing. Full automation for complete testing of all HDMI versions for a device is possible with switch matrix solution which requires a mainframe and switch modules. To learn more about Keysight’s automated switching solution, visit www.keysight.com/find/switching.
Receiver Conformance Test Application for IEEE 802.3ck
Designed to assist and simplify the stress signal calibration used for testing the inputs of IEEE 802.3ck version 2022 chip-to-chip (C2C), chip-to-module (C2M) and coaxial copper (CR) electrical interfaces using Keysight M8040A 64Gbaud Higher Performance BERT or an M8050A 120Gbd High-Performance BERT together with Keysight Digital Communication Analyzer (DCA) Oscilloscope or Infiniium UXR real-time Oscilloscope.
Designed to assist and simplify the stress signal calibration used for testing the inputs of IEEE 802.3ck version 2022 chip-to-chip (C2C), chip-to-module (C2M) and coaxial copper (CR) electrical interfaces using Keysight M8040A 64Gbaud Higher Performance BERT or an M8050A 120Gbd High-Performance BERT together with Keysight Digital Communication Analyzer (DCA) Oscilloscope or Infiniium UXR real-time Oscilloscope.
Receiver Conformance Test Application for IEEE 802.3ck
M8091CKCA
Designed to assist and simplify the stress signal calibration used for testing the inputs of IEEE 802.3ck version 2022 chip-to-chip (C2C), chip-to-module (C2M) and coaxial copper (CR) electrical interfaces using Keysight M8040A 64Gbaud Higher Performance BERT or an M8050A 120Gbd High-Performance BERT together with Keysight Digital Communication Analyzer (DCA) Oscilloscope or Infiniium UXR real-time Oscilloscope.
- Guided Setup, Automated Stress Signal Calibration and Conformance Measurement according to IEEE 802.3ck Standard for chip-to-module (C2M), chip-to-chip (C2C) and coaxial copper (CR) interfaces.
- Remote-controlled Instruments for Test Automation and Reduced User Interaction.
- Data analytics ready.
- Flexible licensing.
Materials Measurement, Resonant Cavity Method for Split Cylinder Resonators
N15007A Resonant cavity method for split cylinder resonators software enables you to evaluate the permittivity characterization of a thin film using the cylindrical cavity fixture.
N15007A Resonant cavity method for split cylinder resonators software enables you to evaluate the permittivity characterization of a thin film using the cylindrical cavity fixture.
Materials Measurement, Resonant Cavity Method for Split Cylinder Resonators
N15007A
N15007A Resonant cavity method for split cylinder resonators software enables you to evaluate the permittivity characterization of a thin film using the cylindrical cavity fixture.
- Easy and repeatable permittivity measurement using Cylindrical cavity measurement methods.
- Suitable for use with the N1501AKEAD-710/720/724/728/735/740/750/760/780 fixture. Maximum frequency coverage is up to 80 GHz.
- Complies with IPC test method TM-650 2.5.5.13.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Keysight N15007A Resonant cavity method for split cylinder resonators software is used with the special fixture, N1501AKEAD, which consists of two halves of a cylindrical cavity that faces each other to form one complete cylindrical cavity resonator. The combination of this fixture with a network analyzer enables repeatable permittivity measurements. This method uses the TE011 mode resonance to measure permittivity. N15007A is fully compatible with the N1500A option 007 Resonant cavity method for split cylinder resonators software.
Materials Measurement, Parallel Plate/Inductance Method up to 120 MHz
N15006A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4990A impedance analyzer and E4980 LCR meter.
N15006A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4990A impedance analyzer and E4980 LCR meter.
Materials Measurement, Parallel Plate/Inductance Method up to 120 MHz
N15006A
N15006A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4990A impedance analyzer and E4980 LCR meter.
- Convenient and easy measurement of permittivity or permeability measurements with the dedicatedly designed parallel plate fixture, 16451B.
- ASTM standard D150 compliant for Parallel plate method.
- Frequency: 20 Hz to 10 M / 20M / 30M / 50M / 120 MHz (E4990A), 20 Hz to 2 MHz (E4980B, E4980A), 20 Hz to 300k / 500k / 1 MHz (E4980BL, E4980AL).
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Keysight N15006A Parallel plate/inductance method software enables to evaluate the permittivity characteristics of a thin film/plate material under test (MUT) with E4990A Impedance analyzer or E4980 series LCR meters. An external PC is necessary to use with E4980 series LCR meters. The 16451B Dielectric Test Fixture was designed for use with these impedance analyzer and LCR meters. The parallel plate method is so called the three terminals method in ASTM standard D150. The measurement frequency range is up to 120 MHz according to the product and option. The N15006A is fully compatible with the N1500A option 006 Parallel plate / inductance software.
Materials Measurement, Parallel Plate/Inductance Method up to 1 GHz
N15005A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4991B impedance analyzer.
N15005A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4991B impedance analyzer.
Materials Measurement, Parallel Plate/Inductance Method up to 1 GHz
N15005A
N15005A Parallel plate/inductance method software enables you to evaluate permittivity and permeability characteristics of a thin sheet of materials with E4991B impedance analyzer.
- Convenient and easy measurement of permittivity or permeability measurements with the dedicatedly designed fixtures (16453A for permittivity, or 16454A for permeability measurements.).
- ASTM standard D150 compliant for Parallel plate method.
- Frequency: 1 MHz to 1 GHz with E4991B impedance analyzer.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Keysight N15005A Parallel plate/inductance method software enables to evaluate the permittivity and permeability characteristics of a thin film material under test (MUT) with E4991B impedance analyzer. Two fixtures are dedicatedly designed and available, 16453A Dielectric Material Test Fixture for the permittivity measurement and 16454A Magnetic Material Test Fixture for the permeability measurement. The parallel plate method is so called the three terminals method in ASTM standard D150. The measurement frequency range is up to 1 GHz for both measurements with E4991B impedance analyzer. The N15005A is fully compatible with the N1500A option 005 Parallel plate / inductance software.
Materials Measurement, Coaxial Probe Method
N15004A Coaxial probe method software enables you to evaluate the dielectric characteristics of the liquid or semi-solids materials with N1501A dielectric probe.
N15004A Coaxial probe method software enables you to evaluate the dielectric characteristics of the liquid or semi-solids materials with N1501A dielectric probe.
Materials Measurement, Coaxial Probe Method
N15004A
N15004A Coaxial probe method software enables you to evaluate the dielectric characteristics of the liquid or semi-solids materials with N1501A dielectric probe.
- Convenient and easy measurement by immersing the probe (N1501A dielectric probe) into liquids or semi-solids material under test(MUT).
- Frequency: 200 MHz to 50 GHz with a network analyzer, 10 MHz to 3 GHz with E4991B impedance analyzer.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others
Keysight N15004A Coaxial probe method software enables to measure the dielectric characterization of your liquid or semi-solids materials conveniently and easily with the combination of the N1501A dielectric probe. No other special fixtures or containers is required. Measurements are non-destructive and can be made in real time. The measurement frequency range is from 200 MHz up to 50 GHz when using on a network analyzer. When using with E4991B impedance analyzer, the frequency range is 10 MHz to 3 GHz. The N15004A is fully compatible with the N1500A option 004 Coaxial probe software.
Materials Measurement, Resonant Cavity Method
N15003A Resonant cavity method software enables you to characterize the thin films, substrate materials and other low loss dielectric materials by the resonant cavity method.
N15003A Resonant cavity method software enables you to characterize the thin films, substrate materials and other low loss dielectric materials by the resonant cavity method.
Materials Measurement, Resonant Cavity Method
N15003A
N15003A Resonant cavity method software enables you to characterize the thin films, substrate materials and other low loss dielectric materials by the resonant cavity method.
- Automates complex permittivity measurement by calculating the resonant frequency and Q parameters measured by a Keysight Vector Network Analyzer.
- Frequency: 1 GHz to 15 GHz.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Materials Measurement, Arch Reflectivity Method
N15002A Arch reflectivity method software enables you to characterize the dielectric and magnetic characteristics by the arch reflectivity method.
N15002A Arch reflectivity method software enables you to characterize the dielectric and magnetic characteristics by the arch reflectivity method.
Materials Measurement, Arch Reflectivity Method
N15002A
N15002A Arch reflectivity method software enables you to characterize the dielectric and magnetic characteristics by the arch reflectivity method.
- Automates complex dielectric and magnetic characteristics measurements by the arch reflectivity method on Keysight Vector Network Analyzers.
- Frequency: 100 MHz to 1.1 THz.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Keysight N15002A Arch reflectivity method allows you to evaluate and characterize your material under test (MUT) using the Arch reflectivity method with Keysight Vector Network analyzers. This method was developed by the U.S. Naval Research Lab and is an useful technique to test angular dependent absorptive characteristics of a material. The measurement frequency range is up to 1.1 THz depending on the instrument and sample holder or fixture used. The N15002A is fully compatible with the N1500A option 002 Arch reflectivity software.
Materials Measurement, Transmission Line and Free Space Method
N15001A Transmission line and free space method software enables you to characterize your material's permittivity and permeability characteristics by the transmission line or free space method.
N15001A Transmission line and free space method software enables you to characterize your material's permittivity and permeability characteristics by the transmission line or free space method.
Materials Measurement, Transmission Line and Free Space Method
N15001A
N15001A Transmission line and free space method software enables you to characterize your material's permittivity and permeability characteristics by the transmission line or free space method.
- Automates complex permittivity and permeability measurements by the transmission line or free space method on Keysight Vector Network Analyzers.
- Frequency: 100 MHz to 1.1 THz.
- Multiple charts and traces aid in data analysis.
- Offline mode enables you to do the data analysis on your PC.
- Measurement report available to share the results to others.
Keysight N15001A Transmission line and free space method software allows you to evaluate and characterize your material under test (MUT) using the transmission line or free space method technologies with Keysight Vector Network analyzers. The measurement frequency range is up to 1.1 THz depending on the instrument and sample holder or fixture used. The N15001A is fully compatible with the N1500A option 001 Transmission line and free space software.
Automotive Ethernet 10BASE-T1S Receiver Compliance Test Software
The AE6930R 10BASE‑T1S Rx Compliance Test Software is a fully automated solution to verify receiver performance of 10BASE‑T1S devices per OPEN Alliance TC14 PMA.
The AE6930R 10BASE‑T1S Rx Compliance Test Software is a fully automated solution to verify receiver performance of 10BASE‑T1S devices per OPEN Alliance TC14 PMA.
Automotive Ethernet 10BASE-T1S Receiver Compliance Test Software
AE6930R
The AE6930R 10BASE‑T1S Rx Compliance Test Software is a fully automated solution to verify receiver performance of 10BASE‑T1S devices per OPEN Alliance TC14 PMA.
10BASE‑T1S is designed to operate on a shared, multidrop bus, where multiple ECUs communicate over a single cable. This environment is inherently noisy, creating reflections, stubs, and interference that can severely impact receiver performance. Even if a transmitter is fully compliant, a weak receiver can cause communication failures once the system is installed in a vehicle.
The AE6930R 10BASE‑T1S Receiver Compliance Test Software provides a fully automated solution for verifying the receiver performance of 10BASE‑T1S devices in accordance with the OPEN Alliance TC14 PMA specifications. Because 10BASE‑T1S operates on a noisy, shared multidrop bus, receiver testing is critical to ensure reliable communication in real automotive environments.
Key capabilities
- Automate 10BASE‑T1S receiver compliance testing
- Recreate real‑world worst‑case conditions
- Simplify complex BER verification
- Test with confidence using a proven Keysight platform
- Test framework with automated report generation
Tests provided
- Bit Error Rate (BER) Verification
- Noise Level Calibration
- Compliance Mode and Expert Mode
The AE6930R Automotive Ethernet Rx Compliance Test Software implements receiver compliance tests defined by:
- OPEN Alliance TC14 PMA Test Suite 5.2
- One primary test case – Receiver BER verification with impaired channel and coupled noise
Ordering information
- Software supports Keysight MXR054B or EXR054A+EXR2WAV.
- Noise source is required.
- Software licenses are available as perpetual node-locked or transportable.
- Software maintenance is available for 12-month increments.
- 10BASE-T1S Media Converter and Accessories are available.
Keysight partner BitifEye Digital Test Solutions provides integrated solutions that complement the Keysight instrument portfolio.
IEEE 802.3dj Electrical Transmitter Compliance Test Software
Experience a fast and automated way to test, debug, and characterize the electrical physical layer based on the IEEE 802.3dj.
Experience a fast and automated way to test, debug, and characterize the electrical physical layer based on the IEEE 802.3dj.
IEEE 802.3dj Electrical Transmitter Compliance Test Software
D90203DJC
Experience a fast and automated way to test, debug, and characterize the electrical physical layer based on the IEEE 802.3dj.
Use the Keysight D90203DJC IEEE 802.3dj transmitter (Tx) test application with Keysight Infiniium UXR-Series oscilloscopes to quickly and accurately perform electrical (physical layer) conformance measurements to meet the following specifications:
- IEEE P802.3dj 200 Gb/s, 400 Gb/s, 800 Gb/s, and 1.6 Tb/s operation.
- 200GAUI-1 C2M, 400GAUI-2 C2M, 800GAUI-4, and 1.6TAUI-8 chip-to-module attachment unit interfaces (C2M) transmitter electrical characteristics.
- 200GBASE-CR1, 400GBASE-CR2, 800GBASE-CR4, and 1.6TBASE-CR8 transmitter electrical characteristics.
- 200GAUI-1 C2C, 400GAUI-2 C2C, 800GAUI-4 C2C, and 1.6TAUI-8 C2C transmitter electrical characteristics.
- 200GBASE-KR1, 400GBASE-KR2, 800GBASE-KR4, and 1.6TBASE-KR8 transmitter electrical characteristics.
The D90203DJC IEEE 802.3dj Tx test application simplifies complex 212 Gbps IEEE transmitter physical layer measurements to help you:
- Reduce time spent understanding the details of standards.
- Decrease the time it takes to characterize your PAM4 design from hours to minutes.
- Enable the debugging of your device using custom configurations.
- Generate HTML reports that summarize the performance of your device quickly.
Key measurements include:
- Jitter measurements Jnu, JRMS, and EOJ on a 12-edge PRBS13Q.
- Output waveform measurements, including steady-state voltage, linear fit pulse ratio, and signal-to-noise-and-distortion ratio (SNDR).
- Effective return loss.
Download and install the D90203DJC free trial onto a Keysight UXR-Series oscilloscope for a comprehensive list of specific tests the application covers.
