HIGHLIGHTS

  • Frequency range of 9 kHz – 3/6 GHz and up to 120 MHz RF modulation bandwidth
  • Perform basic parametric testing of components and functional verification of receivers
  • Test your device with multiple verified, standards-compliant vector signals
  • Easily troubleshoot your component within a wireless communication system using a reliable vector signal generator
  • Minimize downtime and expenses with self-maintenance solutions and low-cost repairs
What's included:
  • Standard output power: +18 dBm
  • Electronic attenuator
  • CW signal generation
  • Vector (IQ) modulator
  • 50-W reverse power protection
  • Country-specific power cord
  • Quick start guide

WICHTIGSTE SPEZIFIKATIONEN

Frequency
9 kHz to 3/6 GHz
Output Power @1 GHz
+18 dBm
Frequency Switching (Typical)
< or equal to 5 ms, typical
Harmonics @1 GHz
< -35 dBc
Phase Noise @1 GHz (20 kHz offset)
-119 dBc/Hz
Type
Vector
Frequency
Output Power @1 GHz
Frequency Switching (Typical)
Harmonics @1 GHz
Phase Noise @1 GHz (20 kHz offset)
Type
9 kHz to 3/6 GHz
+18 dBm
< or equal to 5 ms, typical
< -35 dBc
-119 dBc/Hz
Vector
Mehr anzeigen
Amplitude Modulation-Maximum Depth:
1
Amplitude Modulation-Rate:
0 to 50 kHz
Applications Available:
Baseband Generator Mode:
Waveform Playback
Frequency:
9 kHz to 3/6 GHz
Frequency Modulation-Maximum Deviation @1 GHz:
10 MHz
Frequency Modulation-Rate @100 kHz Deviation:
DC to 7 MHz
Frequency Options:
3, 6 GHz
Frequency Switching (Typical):
< or equal to 5 ms, typical
Harmonics @1 GHz:
< -35 dBc
IQ Modulation BW Internal/External:
120 MHz
Non-Harmonics @1 GHz:
< -72 dBc
Output Power @1 GHz:
+18 dBm
Performance Level:
◆◆◇◇◇◇
Phase Modulation-Maximum Deviation:
5 radians, nominal
Phase Modulation-Maximum Deviation in High-BW Mode:
0.2 radians, nominal
Phase Noise @1 GHz (20 kHz offset):
-119 dBc/Hz
Software-Audio/Video Broadcasting:
Support waveform playback with 5-pack or 50-pack
Software-Cellular/Wireless Connectivity:
Bluetooth®
cdma2000®/1xEV-DO
GSM/EDGE/Evo
LTE/ LTE-Advanced FDD and TDD
TD-SCDMA/HSPA
W-CDMA/HSPA+
WLAN 802.11a/b/g/j/p/n/ac/ah/ax
Pre-5G
5G NR
IoT (Zigbee, Z-Wave, WiSUN, and LoRa)
V2X
DFS Radar Profiles
Software-Detection/Positioning/Tracking/Navigation:
Global Navigation Satellite System
Software-General Purpose:
Custom modulation
Analog I/Q Input
I/Q Waveform
MATLAB
Multitone
Pulse
Sweep Mode:
Schritt
Liste
Type:
Vector
Waveform Playback Memory:
512 Msa

PathWave Signal Generation


  • Signal creation software with waveform playback and real-time signal creation capabilities
  • Component and receiver test for a broad range of applications across evolving wireless systems
  • Scalable capability and performance

Other Software for the CXG

Download your next insight

  • Customize your measurements and signals with MATLAB
  • Perform commands and easily create, edit and replay command sequences
