How to Isolate CAN Bus Arbitration

+ Essential Benchtop Oscilloscope

Trigger on Specific Arbitration Events

Isolating CAN bus arbitration requires identifying activity within the arbitration portion of the frame while limiting captures to the messages engineers want to examine. The test setup needs an oscilloscope that can identify the waveform region where arbitration occurs and qualify the trigger using a specific CAN frame identifier (ID) or symbolic message name.

Engineers establish a trigger zone over the first few bits of the CAN frame where arbitration occurs and combine that zone with the selected message condition. Once the desired arbitration event is isolated, segmented memory can capture consecutive occurrences so engineers can review individual events and characterize how often the arbitration condition occurs.

CAN Bus Arbitration Analysis Solution

Isolating CAN bus arbitration requires an oscilloscope that can combine waveform-based triggering with CAN message qualification and selectively capture repeated events. A Keysight Essential benchtop oscilloscope captures the CAN physical-layer waveform, while automotive analysis software provides CAN decoding and message-based trigger qualification. Zone triggering defines the waveform region where arbitration occurs and combines it with a specific frame ID or symbolic message name to isolate the desired event. Segmented memory then captures consecutive arbitration occurrences for individual review and analysis of how often the condition occurs.

Get Quote

See Demo of Automotive Serial Bus Characterization

Explore Products in Our CAN Bus Arbitration Analysis Solution

HD300AUTA Automotive Analysis Software Package for HD3

Learn More Request a Trial
HD304MSO InfiniiVision Oscilloscope: 4 Analog Channels

Learn More View Data Sheet
