• Verified test set developed before the release of 3GPP FR2 MIMO OTA
• Validated channel models for FR2 MIMO OTA according to the TR38.901 test specification
• Predefined and customizable beam management performance test cases
• State-of-the art logging, visualization, and debugging tools to resolve issues more quickly

The Advanced Performance Test Software offers advanced performance testing beyond standard requirements by providing predefined test cases and customizable test scripts to meet specific customer requirements.

• Real-world lab test environment for validating 5G devices under a wide range of network signaling and radio channel conditions.
• Fully controlled test scenario enabling quick and systematic performance validation.
• Ready-to-run test cases based on real-world drive test routes from various parts of the world.
• The optional Field-to-Lab tool enables users to create test cases from their own field logs.

The Virtual Drive Test Software enables you to efficiently analyze the performance of 5G new radio (NR) devices deployed in non-standalone (NSA) or standalone (SA) networks and under various mobility scenarios.

• Simple parameter management
• Automated device testing
• Test case progress monitoring

• Test case source code review and modification
• Quick test results analytics
• Test reports generation

• Access to a wide range of Regulatory test plans across regions.
• Tools to customize FR1 and FR2 Universal Regulatory test cases for required test frequencies and test limits defined by the Regulators.
• Modular and scalable software.

• Flexible Licensing infrastructure that allows optimal asset utilization.
• Comprehensive campaign management.
• Unattended test campaign execution with device automation.
• Advanced logging features.

Test Across the Workflow with Interactive, Full-Featured Software

The C8700200A Test Application Software provides real-time testing across the full chipset and device development workflow from early prototype testing through integration, verification, and acceptance. The powerful GUI delivers a high level of autonomy in configuration and parameterization with full access to 5G NR scheduling to test many use cases.

Verify RF performance and functional KPI of wireless chipsets and devices using real-time network emulation and end-to-end IP data throughput analysis. Develop test automation with SCPI or use the C8702000A RF Automation Toolset and the C870300A Functional KPI Toolset with built-in test scenarios for RF and functional testing.

Be ready for the future with high-performance capability:

• The latest enhancements including RedCap and NTN

• Dynamic port mapping and internal switching for reduced errors and efficient connectivity

• FR1 and FR2 coverage including 5G NR-U

• Flexible scheduling and band combination testing

• Fast processing for efficient analysis and troubleshooting
• Integrated IMS and IP impairments for voice and video testing
• Block error ratio (BLER) testing in real time for each technology and component carrier
• End-to-end IP data throughput testing
• Battery drain testing
• RF testing to 3GPP performance requirements and beyond

Keysight's C8714000A RF Application Software reduces the need for protocol expertise with intelligent signaling. Select built-in 3GPP tests, SAR tests, and maximum throughput tests to automatically configure parameters. Efficient usability makes test development and execution quick and easy.

Modify parameters essential to RF testing during a live connection. Changes are made in the background with no user intervention. Use a blind handover to modify multiple parameters simultaneously.

Save test development time with built-in tests. The RF Application Software automatically configures parameters for the selected test according to 3GPP and starts the measurement. Select from LTE, 5G NR NSA, SA, 2UL CA, UL MIMO, Tx diversity, SAR, and maximum throughput tests.

Verify device RF performance under carrier aggregation conditions. Configure up to four 5G NR cells and up to six LTE cells. Then, analyze multiple measurement results for each cell.

The RF Application Software is optimized for speed using Keysight’s UXM 5G Wireless Test Platform to make RF measurements in parallel with an embedded measurement engine.

• Simple parameter management
• Automated device testing
• Test case progress monitoring

• Test case source code review and modification
• Quick test results analytics
• Test reports generation

• Access to wide range of Regulatory test plans across regions
• Tools to customize FR1 Universal Regulatory test cases for required test frequencies and test limits defined by the Regulators
• Modular and scalable software

• Flexible Licensing infrastructure that allow optimal asset utilization
• Comprehensive campaign management
• Unattended test campaign execution with device automation
• Advanced logging features

• Tools to customize test cases by adding new test points, modifying channel bandwidth, test frequencies, and other parameters, to go beyond industry requirements defined by 3GPP in the DVT mode.

• Modular and scalable software.

• Comprehensive campaign management.

• Access to approximately 80% of total validated test cases in the Benchtop configuration, both FR1 and FR2.

• Unattended test campaign execution with device automation.
• Advanced logging features to rapid debugging of test case failures.

• Modular and scalable software and hardware platform
• Access to approximately 80% of total validated test cases in the Benchtop configuration, both FR1 and FR2
• Flexible licensing infrastructure that allows optimal asset utilization
• Comprehensive campaign management
• Advanced logging features that enable rapid debugging of test case failures
• Unattended test campaign execution with device automation

The RF/RRM Conformance Test Software provides up-to-date and comprehensive access to 5G NR and C-V2X RF, Demod and RRM conformance test cases. The S8705A is an approved test platform for device certification at GCF and PTCRB that supports both TDD and FDD and all relevant bands in both sub-6GHz (FR1) and mmWave (FR2) frequencies.

• Simple parameter management
• Automated device testing
• Test case progress monitoring

• Test case source code review and modification
• Quick test results analytics
• Test reports generation

• Leading coverage of RF/RRM carrier acceptance test plans

• Comprehensive campaign management capabilities
• Test report generation summarizing test campaign results


• Advanced logging features that enable rapid debugging of test case failures
• Unattended test campaign execution with device automation

Full RF Functional Testing for LTE, 5G NR Devices, NB-NTN, RedCap, C-V2X and WLAN Devices​

The ultimate RF Automation test software provides an environment to create test campaigns using pre-defined transmitter and receiver measurement test cases for:

• LTE and 5G NR devices in accordance with the 3GPP TS 36.521 specifications.
• WLAN test cases, including Wi-Fi 7, in accordance with IEEE specifications.
• Test cases to verify performance for NB-IoT technologies like RedCap and NB-NTN.
• CV2X based on 3GPP and Omniair specifications.


Use the test software to create and perform fully automated RF test scenarios for device full RF functional testing, fast Go / No-Go verification for repair,  RF design regression, and validation, and even pre-conformance testing.
