Make an Inspired Connection with X-Series Signal Analyzers

Engineering is all about connecting ideas and solving problems. This starts with accessible performance, which is at the heart of every X-Series signal analyzer. They put you closer to the answer by easily linking cause and effect. Across the full spectrum — from our CXA to our UXA — you will find the signal analysis tools you need to design, test, and deliver your next breakthrough. Reach for the X-Series signal analyzer and make an inspired connection.

Achieve deeper troubleshooting and one-button measurements with the broadest set of application-specific software
Drive consistent measurements across your organization, no matter which instruments you choose to use, with 100% code-compatibility from research and development (R&D) to manufacturing

Simplify measurement setup and customize views with the new multi-touch user interface
See, capture, and understand the most elusive signals — known or unknown — with real-time spectrum analysis

View Brochure

Get Closer to Your Answer with Accessible Performance

Measurement setup is simple with the X-Series' multi-touch user interface, customizable views, and one-button measurements. Not only are measurements easy, but you can capture signals you could not see before with a spurious-free dynamic range of > 75 dBc. You can also accurately measure low-level signals with noise floor extension (NFE) to reduce measurement noise by up to 10 dB.

Achieve easy, accurate, and detailed measurements with Keysight's X-Series signal analyzers.

Find the Model That's Right for You

Already own one of these products? Visit Technical Support

N9042B

N9042B UXA Signal Analyzer, 2 Hz to 110 GHz

Starting from

Frequency: 2 Hz to 50 GHz, with V3050A 110 GHz

Bandwidth Options: 1, 1.5, 2, and 4 GHz

DANL @1 GHz: -174 dBm

Overall Amplitude Accuracy: ± 0.24 dB

Phase Noise @1 GHz (10 kHz offset): -135 dBc / Hz

N9041B

N9041B UXA Signal Analyzer, 2 Hz to 110 GHz

Starting from

Frequency: 2 Hz to 110 GHz

Bandwidth Options: 25 MHz standard, 40 MHz, 1 GHz

DANL @1 GHz: -174 dBm

Overall Amplitude Accuracy: ±0.16 dB

Phase Noise @1 GHz (10 kHz offset): -135 dBc / Hz

N9040B

N9040B UXA Signal Analyzer, 2 Hz to 50 GHz

Starting from

Frequency: 2 Hz to 50 GHz

Bandwidth Options: 25 standard, 40, 255, 510 MHz, 1 GHz

DANL @1 GHz: -174 dBm

Overall Amplitude Accuracy: ±0.16 dB

Phase Noise @1 GHz (10 kHz offset): -135 dBc / Hz

N9032B

N9032B PXA Signal Analyzer, 2 Hz to 26.5 GHz

Starting from

Frequency: 2 Hz to 26.5 GHz

Bandwidth Options: 1, 1.5, and 2 GHz

DANL @1 GHz: -174 dBm

Overall Amplitude Accuracy: n/a

Phase Noise @1 GHz (10 kHz offset): -136 dBc/Hz

N9030B

N9030B PXA Signal Analyzer, 2 Hz to 50 GHz

Starting from

Frequency: 2 Hz to 50 GHz

Bandwidth Options: 25 standard, 40, 85, 125, 160, 255, 510 MHz

DANL @1 GHz: -174 dBm

Overall Amplitude Accuracy: ±0.19 dB

Phase Noise @1 GHz (10 kHz offset): -136 dBc/Hz

N9021B

N9021B MXA Signal Analyzer, 10 Hz to 50 GHz

Starting from

Frequency: 10 Hz to 50 GHz

Bandwidth Options: 255, 510 MHz

DANL @1 GHz: -172 dBm

Overall Amplitude Accuracy: ±0.19 dB

Phase Noise @1 GHz (10 kHz offset): -130 dBc/Hz

N9020B

N9020B MXA Signal Analyzer, 10 Hz to 50 GHz

Starting from

Frequency: 10 Hz to 50 GHz

Bandwidth Options: 25 standard, 40, 85, 125, 160 MHz

DANL @1 GHz: -172 dBm

Overall Amplitude Accuracy: ±0.23 dB

Phase Noise @1 GHz (10 kHz offset): -114 dBc/Hz

N9010B

N9010B EXA Signal Analyzer, 10 Hz to 44 GHz

Starting from

Frequency: 10 Hz to 44 GHz

Bandwidth Options: 10 standard, 25, 40 MHz

DANL @1 GHz: -170 dBm

Overall Amplitude Accuracy: ±0.27 dB

Phase Noise @1 GHz (10 kHz offset): -109 dBc/Hz

N9000B

N9000B CXA Signal Analyzer, 9 kHz to 26.5 GHz

Starting from

Frequency: 9 kHz to 26.5 GHz

Bandwidth Options: 10 standard, 25 MHz

DANL @1 GHz: -163 dBm

Overall Amplitude Accuracy: ±0.50 dB

Phase Noise @1 GHz (10 kHz offset): -110 dBc/Hz

View and Compare All Models

X-Series signal Analyzer Applications — Simplify Complex Measurements and Deliver Repeatable Results

Understand the performance of your cellular, wireless, and aerospace/defense devices and designs with downloadable X-Series measurement applications.

Gain more insight into device performance from basic measurements to the latest standards-compliant wireless measurements like 5G, IoT, LTE and WLAN with integrated applications that put consistent measurements at your fingertips
Share same measurement science and expertise across multiple hardware platforms across design, development, and production
Choose the best license type and terms according your need and budget

Extend Your Capabilities with the Right Tools

Get more functionality out of your existing hardware today by pairing it with the right accessories to improve productivity and the right Keysight PathWave design and test automation software to accelerate your product development.
