HIGHLIGHTS

The U2000 Series is supported by the Keysight BenchVue software. BenchVue makes it easy to control your power meter, log data, and visualize measurements in a wide array of display options without any programming. Simply connect the sensor to your PC installed BenchVue BV0007B Power Meter/Sensor Control and Analysis app to perform average power measurements and analysis.

  • Frequency range of 9 kHz to 6 GHz
  • Wide dynamic range of -60 to +20 dBm
  • Internal zeroing capability to eliminate external calibration
  • High measurement speed of up to 250readings/second
  • Support internal/external trigger measurements, internal triggering and trace display
  • Display power measurements on a PC or other Keysight’s instruments
  • BenchVue software license (BV0007B) included with your instrument makes it simple to connect, control instruments, and automate test sequences
  • Fully firmware compatible with selected Keysight instruments

KEY SPECIFICATIONS

Channels
1
Compatible Power Sensors / Power Meters
N1913A/14A
Connector Type
N-Type (m)
Features
Come with BenchVue PM App software license, BV0007B
Frequency Range
9 kHz to 6 GHz
Power Range
-60 dBm to +20 dBm
Channels
Compatible Power Sensors / Power Meters
Connector Type
Features
Frequency Range
Power Range
1
N1913A/14A
N-Type (m)
Come with BenchVue PM App software license, BV0007B
9 kHz to 6 GHz
-60 dBm to +20 dBm
View More
Channels:
1
Compatible Power Sensors / Power Meters:
N1913A/14A
Connector Type:
N-Type (m)
Features:
Come with BenchVue PM App software license, BV0007B
Frequency Range:
9 kHz to 6 GHz
Power Range:
-60 dBm to +20 dBm
Speed:
110 readings / sec at Fast mode
