Highlights

The U2000 Series is supported by the Keysight BenchVue software. BenchVue makes it easy to control your power meter, log data, and visualize measurements in a wide array of display options without any programming. Simply connect the sensor to your PC installed BenchVue BV0007B Power Meter/Sensor Control and Analysis app to perform average power measurements and analysis.

NEW! Internal triggering and trace display capability

Internal triggering enables triggering based on the burst signal envelope, eliminating the need for an external triggering signal. Trace display provides a graphical view of the signal envelope to assist in gate placement and trigger level setup. All U2000 sensors, except for the U2004A, feature these new capabilities. If you are a current USB sensor user, simply download the U2000 series USB power sensor firmware upgrade free or charge.

  • Frequency range of 50 MHz to 24 GHz
  • Extended frequency of 10 MHz to 26.5 GHz with option H26
  • Wide dynamic range of -60 to +20 dBm
  • Internal zeroing capability to eliminate external calibration
  • High measurement speed of up to 250 readings/second
  • Support internal/external trigger measurements, internal triggering and trace display
  • Display power measurements on a PC or other Keysight’s instruments
  • A BenchVue software license (BV0007B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequences.
  • Fully firmware compatible with selected Keysight instruments

KEY SPECIFICATIONS

Channels
1
Compatible Power Sensors / Power Meters
N1913A/14A
Connector Type
3.5mm (m)
Features
Come with BenchVue PM App software license, BV0007B
Frequency Range
10 MHz to 26.5 GHz Sensor option dependant
Power Range
-60 dBm to +20 dBm
Channels
Compatible Power Sensors / Power Meters
Connector Type
Features
Frequency Range
Power Range
1
N1913A/14A
3.5mm (m)
Come with BenchVue PM App software license, BV0007B
10 MHz to 26.5 GHz Sensor option dependant
-60 dBm to +20 dBm
View More
Channels:
1
Compatible Power Sensors / Power Meters:
N1913A/14A
Connector Type:
3.5mm (m)
Features:
Come with BenchVue PM App software license, BV0007B
Frequency Range:
10 MHz to 26.5 GHz Sensor option dependant
Power Range:
-60 dBm to +20 dBm
Speed:
110 readings / sec at Fast mode
