87106R Low-PIM Coaxial Switch, DC to 26.5 GHz, SP6T
Ensure signal integrity, improve testing efficiency, and maximize test throughput with low PIM performance of -160 dBc
Starting from
HIGHLIGHTS
Low passive intermodulation (PIM) is crucial for applications where two or more transmitted signals share an antenna or whenever the transmitter signal is too high or the receiver is sensitive to high intermodulation. The Keysight 87106R is a low-PIM SP6T coaxial switch, operating from DC to 26.5 GHz, that can help keep the system PIM level low. A guaranteed 0.03 dB insertion loss repeatability and 3 million cycles of operating life ensure signal integrity, improve testing efficiency, and ultimately maximize test throughput.
- low PIM performance of -160 dBc
- guaranteed 0.03 dB insertion loss repeatability
- guaranteed 3 million cycles per section of operating life
- excellent isolation to minimize cross-talk between channels to ensure signal integrity
For more information about Keysight switches, please visit RF & Microwave Electromechanical Switches pages.
