Millimeter-wave and Microwave GaAs Switches
Keysight Technologies provides MMIC switches ideal for microwave radio, aerospace and defense, and instrumentation applications.
Highlights
Keysight Technologies provides MMIC switches ideal for microwave radio, aerospace and defense, and instrumentation applications.
These switches operate from DC to 8 GHz and feature low insertion loss and high isolation in this frequency range.
These parts are sold exclusively through distribution. Please use the ‘How to Buy’ link to contact your local distributor.
(1Gxx products are for sale to select customer only)
For more information about MMIC, please visit MMIC millimeter-wave and microwave devices
Products
1GG6-8054 DC-75 GHz SPDT GaAs Switch IC
The 1GG6-8054 is a GaAs monolithic microwave integrated circuit (MMIC) switch designed for low insertion loss and high isolation from DC to 75 GHz
- Frequency Range: DC-75 GHz
- Insertion Loss: 2.6 dB typical @ 50 GHz
- Isolation: 29 dB typical @ 50 GHz
- Return Loss: >10 dB (Both Input and Selected Output)
- P-1dB: +17 dBm
- Harmonics: <-50 dBc
- Settling Time: < ns (0.1 dB)
1GG7-8157 DC–20 GHz SPDT GaAs MMIC Switch
The 1GG7-8157 (TC752) is a GaAs monolithic microwave integrated circuit (MMIC) designed for low insertion loss and high isolation from DC to 20 GHz
- Frequency Range: DC–20 GHz
- Insertion Loss: 1.4 dB typ @ 20 GHz
- Isolation: >70 dB @ 45 MHz, 20 dB @ 20 GHz
- Return Loss: 15 dB typ
- Switching Speed: <1 ns (10%–90% RF)
- P–1dB: 25 dBm @ 10 MHz, 26 dBm @ 2 GHz
- Harmonics (DC coupled):SHI >75 dBm typ, THI >50 dBm typ
HMMC-2007 DC-8 GHz SPDT Absorptive GaAs Switch IC
The HMMC-2007 is a general purpose SPDT absorptive switch designed for low insertion loss and high isolation from DC to 8 GHz
- Outputs Terminated in 50Ω when off
- Frequency Range: DC – 8 GHz
- Insertion Loss: 1.2 dB @ 8 GHz
- Isolation: >70 dB @ 45 MHz >35 dB @ 8 GHz
- Return Loss: 25 dB (Both Input and Selected Output)
- 18 dB Unselected Output
- Switching Speed: <20 μs (10%-90% RF)
- P-1dB: 27 dBm
HMMC-2027 DC-26.5 GHz SPDT Absorptive GaAs Switch IC
The HMMC-2027 is a general purpose SPDT absorptive switch designed for low insertion loss and high isolation from DC to 26.5 GHz
- Outputs Terminated in 50Ω when off
- Frequency Range: DC – 26.5 GHz
- Insertion Loss: 2.5 dB @ 26.5 GHz
- Isolation: >70 dB @ 45 MHz >30 dB @ 26.5 GHz
- Return Loss: 15 dB (Both Input and Selected Output) 12 dB Unselected Output
- Switching Speed: < 1 ns (10%-90% RF) P-1dB: 18 dBm @ 10 MHz / 27 dBm @ 2 GHz
- Harmonics (DC Coupled): < -45 dBc @ 10 MHz and 5 dBm / < -65 dBc @ 2 GHz and 5 dBm
HMMC-5627-BLK 2-26.5 GHz SPDT GaAs Packaged MMIC Switch
The HMMC-5627 is a GaAs monolithic microwave integrated circuit (MMIC) packaged in a 2 x 2 mm, 12 lead QFN
- Outputs terminated in 50Ω when off
- Frequency Range: DC – 26.5 GHz
- Insertion Loss: 2.5dB @ 26.5 GHz
- Isolation: >70 dB @ 45 MHz, 30 dB @ 26.5 GHz
- Return Loss: 15 dB (Both Input and Selected Output), 12 dB Unselected Output
- Switching Speed: <1 ns (10%-90% RF)
- P-1dB: 18 dBm @ 10 MHz, 27 dBm @ 2 GHz Harmonics
- (DC coupled): <−45 dBc @ 10 MHz and 5 dBm <−65 dBc @ 2 GHz and 5 dBm
HMMC-5627-TR1 2-26.5 GHz SPDT GaAs Packaged MMIC Switch
The HMMC-5627 is a GaAs monolithic microwave integrated circuit (MMIC) packaged in a 2 x 2 mm, 12 lead QFN
- Outputs terminated in 50Ω when off
- Frequency Range: DC – 26.5 GHz
- Insertion Loss: 2.5dB @ 26.5 GHz
- Isolation: >70 dB @ 45 MHz, 30 dB @ 26.5 GHz
- Return Loss: 15 dB (Both Input and Selected Output), 12 dB Unselected Output
- Switching Speed: <1 ns (10%-90% RF)
- P-1dB: 18 dBm @ 10 MHz, 27 dBm @ 2 GHz Harmonics
- (DC coupled): <−45 dBc @ 10 MHz and 5 dBm <−65 dBc @ 2 GHz and 5 dBm
