Keysight PZ2121A
High-Speed Precision SMU / 15 MSa/s / 100 fA / 60 V / 3.5 A / DC/10.5 A Pulse
Keysight PZ2121A
High-Speed Precision SMU / 15 MSa/s / 100 fA / 60 V / 3.5 A / DC/10.5 A Pulse
CNY 34,847.70
原价 CNY 116,159.00
是德科技原厂二手仪器
Keysight PZ2121A CNY 34,847.70
从
CNY 34,847.70 节省 70%
安心体验，基于是德科技的专业保障：KeysightCare Assured 服务+ 原厂校准服务
|
Fresh Calibration* 交付周期延长约4周 | CNY 3,516.00 |
|
KeysightCare Assured - 1 year 包括是德科技延长保修 | CNY 5,076.00 |
|
KeysightCare Assured - 2 years 包括是德科技延长保修 | CNY 10,152.00 |
|
KeysightCare Assured - 3 years 包括是德科技延长保修 | CNY 15,228.00 |
|
KeysightCare Assured - 5 years 包括是德科技延长保修 | CNY 25,380.00 |
*若仪器尚未校准（详见商品详情），需先完成校准方可购买 KeysightCare 计划。
The Keysight PZ2121A is a high-speed precision source / measure unit (SMU) featuring narrow-pulse width, fast Digitizer Mode, and seamless current measurement ranging. It enables narrow-pulsed measurements and fast dynamic measurements with a wide dynamic range for a wide range of emerging applications such as vertical-cavity surface-emitting laser (VCSEL) optical devices, integrated circuit (IC) testing. In addition, its low measurement noise performance enables measurements with shorter aperture times, and its seamless current measurement ranging function enables a wide dynamic range and eliminates range change time, which improves test throughput.
- Maximum output at 60 V / 3.5 A DC / 10.5 A pulse
- Minimum resolution at 6 μV/100 fA
- Low current measurement noise at 400 fArms with 1 power line cycle (PLC)
- Minimum pulse width at 10 μs
- Fast Digitizer Mode with maximum sampling rate at 15 MSa/s
- Wide dynamic range for dynamic measurement with seamless current measurement ranging
- Fast transient with 3.5 V/μs slew rate at max
