HIGHLIGHTS

  • The fastest throughput oscilloscope solution for triggering on and analyzing I2C and SPI serial buses.
  • Support for the I2C serial protocol.
  • Support for the 2-wire and 3-wire SPI serial protocol.
  • On-screen serial decode synchronized with the serial data waveform.
  • Hexadecimal display format.

The I2C and SPI Serial Decode Option for InfiniiVision Series oscilloscopes (5000, 6000, and 7000 Series) display responsive, time-aligned, on-screen decode of Inter-Integrated Circuit (I2C) and 2-wire or 3-wire Serial Peripheral Interface (SPI) serial communication buses. The N5423A provides the fastest throughput solution for triggering on and analyzing I2C and SPI serial buses found in a wide variety of embedded designs. You can easily isolate serial packets to find sources of errors due hardware or software related problems.

This software option works with Keysight 4-channel DSOs, or 4+16-channel MSOs only.

Free Trials

Get a 30-day trial license for N5423A.

The N5423A I2C/SPI triggering/decode option is enabled with a license key on the Keysight InfiniiVision oscilloscopes, so there are no files to download and install.

Interested in a N5423A?

Extend the Capabilities for your I²C and SPI Serial Data Decode Option for InfiniiVision 6000 and 7000B Series Oscilloscopes
