Powerful and Flexible Capability

The SI package adds powerful tools to measure impedances, transfer characteristics and S-parameter calculations to the basic TDR/TDT measurements. FlexDCA includes basic oscilloscope measurements that are enhanced with the additional capabilities this signal integrity package provides.

For a mapping of legacy FlexDCA feature-based options to each of the software packages available, refer to DCA Configuration Guide under N1010x00A Analysis Packages mapping table.
