Design Cloud (HPC)

The W3039E EM HPC 1-pack includes:

• Spend less time waiting on large EM extraction
• Simulate more test cases to reduce risk
• Easily accessible high performance computing, freeing your local PC from computational tasks

With project timelines tighter than ever, utilize a quantity of W3039E elements to significantly reduce the time it takes to run large EM extractions. High performance computing allows you to be more productive by waiting less time for an EM extraction and simulate more test cases to reduce risk. This solution has made high performance computing easy, as you can setup your simulation, let it run, freeing your local machine from computation tasks, and reconnect to view your results. This requires an EM simulator license (ex: SIPro + 3 x HPC 1-Pack = 4 parallel jobs).

Note: This element license requires a host bundle to work. For recommended bundle configurations, click here.

The W3029E Ckt Sim HPC 1-pack includes:

• Reduce simulation time with parallel jobs
• Free your PC from computational tasks
• Simulate more to reduce risk before the next design-stage

The W3029E enables you to perform batch and sweep simulations in a parallelized manner to significantly reduce simulation time. This solution has made high performance computing easy, as you can set up your simulation, let it run, freeing your PC from computational tasks, and reconnect to view your results.

Note: This element license requires a host bundle to work. For recommended bundle configurations, click here.

The W3059E Electro-Thermal (ETH) High Performance Computing (HPC) Accelerator includes:

• The industry’s highest spatial temperature resolution for the most accurate and reliable circuit analysis in tightly integrated 3D modules.
• Parallelization option to run on HPC with a 10x typical speedup.
• Flexibility for incremental additions to achieve optimal speed.

Keysight ETH simulation provides the industry’s highest spatial temperature resolution for the most accurate and reliable circuit analysis in tightly integrated 3D modules. Swept ETH circuit simulation can be parallelized to run on HPC with a 10x typical speedup. ETH HPC Accelerator can be incrementally added to achieve the optimal speedup.

The W4581E SystemVue HPC Design Cloud software supports:

• Run parallel simulations in a cluster or server to reduce simulation time and expedite time-to-market significantly.
• Launch multiple simulations, shut down and walk away, Keysight Design Cloud ensures jobs are done quickly and securely and results are ready once you reconnect.
• Run on both Windows and Linux operating systems

The W4581 SystemVue HPC Design Cloud accelerates and manages multiple parameterized sweep simulations for RF, Phased Array, and Dataflow designs. It provides a comprehensive set of job creation, allocation and submission capabilities, and returns results as a single dataset. The HPC license leverages High-Performance Computing (HPC) technologies that enables users to run parallel simulations in the cloud, cluster, or server to make sure jobs are automatically allocated to the right resources for maximum application performance and efficiency. Communications system architects, verification engineers, and baseband designers use the HPC license to accelerate architecture studies and verification suites, while reducing costs and accelerating time-to-results.

For further information on Keysight Design Cloud, please visit Keysight Design Cloud
