PathWave ADS:
High-Speed Digital

Overcome challenges in gigabit design

High-speed digital standards are evolving to keep pace with emerging technologies such as 5G, Internet of Things (IoT), and autonomous vehicles. Each change introduces new and more complex challenges that can degrade the signal in your digital design. Keysight’s simulation software can help you anticipate and overcome new test challenges for your digital designs. Use it today to optimize your design's performance, lower cost and realize more predictable design outcomes.

Overcome Signal Integrity Issues

Whether you design for the latest evolution of PCI Express or push boundaries with PAM-4 signaling, overcoming challenges in high-speed serial design takes hours of design time. Gain design efficiency using integrated channel and electromagnetic (EM) simulation. Accurately simulate complex signal links with jitter, equalization, and clock and data recovery with the channel simulator and IBIS-AMI models. Obtain high-accuracy EM models in minutes rather than hours.

Designing for Power Integrity

Power Integrity (PI) issues can cost thousands of dollars to fix. Unnoticed power integrity issues lead to poor product reliability. You need a cohesive design flow for frequency and time-domain analysis of power distribution networks (PDNs). Get software tools to enable power-aware signal integrity analysis.

Address DDR Memory Challenges

Double Data Rate (DDR) memory system designers contend with shrinking timing and voltage margins, and an increasing number of compliance measurements. They must also perform numerous receiver mask tests at ultra-low bit error rates.

With Keysight’s Memory Designer software, DDR memory designers can now extract EM models, simulate buses, and perform compliance testing faster. And because the same measurement science is used for both simulation and hardware verification, they can easily compare simulation and measurements.

Find the Product that's Right for You

Bundles

Model Number Bundle Name Description
W2222BP Power Integrity Bundle ADS Core, TransConv, Harmonic Balance, Layout, PIPro Learn More
W2223BP
 Signal Integrity Bundle ADS Core, TransConv, Channel, IT, Layout, SIPro, PIPro Learn More
W2225BP
 Memory Designer Bundle ADS Core, TransConv, Channel, IT, Layout, SIPro, PIPro, and Memory Designer Learn More

Simulation Elements

Model Number Bundle Name Description
W2360EP SIPro EM Analysis Element Provides signal integrity analysis of your high-speed printed circuit boards (PCBs) Learn More
W2359EP
 PIPro EM Analysis Element
 Provides power integrity analysis of your PDN Learn More
W2393EP Memory Designer Element Minimizes the effort required to setup and extract EM models, simulate buses, and perform compliance testing
 Learn More
W2309EP
 DDR Bus Simulator Quickly generates accurate bit-error-rate (BER) contours, masks, and margins via statistical simulation Learn More
W2307EP Interconnect Toolbox Element Enables you to optimize your PCB stack up and transmission line geometry using metrics that matter Learn More
W1714EP AMI Modeling Kit Optimizes the signal processing blocks for your Serializer/Deserializer (SerDes) integrated circuit Learn More
W2350EP DDR3 Compliance Test Bench Provides a simulation-measurement correlation and workflow for DDR3 Compliance Learn More
W2351EP DDR4 Compliance Test Bench Provides a simulation-measurement correlation and workflow for DDR4 Compliance Learn More
