The rate of technology innovation in the automotive industry is exciting and continuously growing. Keysight Technologies, along with our partners, help ensure vehicle systems work reliably, conform to standards, and provide the needed safety and security through our comprehensive automotive test solutions. Come learn from our technical experts using state-of-the-art test equipment and see what Keysight can do for you.
Attendance is no charge, but seats are limited, so please make sure you register soon.
Automotive Ethernet - Next Generation Automotive Serial Bus
March 3, 2020
5301 Stevens Creek Blvd
Santa Clara, CA 95051
Building 4 - Ramanujan Room
All versions of Automotive Ethernet require rigorous testing: IEEE 802.3bw, IEEE 802.3bp, and OABR 3.2. Time Sensitive Networking (TSN) is an extension to IEEE 802.1 that makes Ethernet deterministic, more robust, and more reliable. The specified tests covering transmitters, receivers, and harness/connector assemblies, are more complex than what most automotive engineers have done in the past. When you move to this new evolving technology with complex test requirements, be prepared.
Participate in hands-on labs to learn how to test and make critical measurements on Ethernet based designs. Keysight will show solutions to address 100Base-T1 and 1000Base-T1, electrical, protocol, and link segments based on our Infinium real-time oscilloscopes and vector network analyzers.
After presenting a technical overview, this workshop will include three separate breakout sessions with demonstrations:
- Breakout Session #1: Physical Layer – Time-Domain/Oscilloscope Based
- Breakout Session #2: Physical Layer – Frequency Domain/Network Analyzer Based
- Breakout Session #3: Up the Stack – Capture of Live Traffic at the Higher Layer
8:30 a.m. - Registration and Refreshment
9:00 a.m. - Introductions
9:15 a.m. - Update on High-Speed Vehicle Network Standards
9:30 a.m. - Time Sensitive Network (TSN) Conformance and Performance
- Why Ethernet?
- What parameters matter at the higher layers?
9:50 a.m. - Automotive Ethernet Basics
10:50 a.m. - Break
11:00 a.m. - Breakout Session #1
12:00 p.m. - Lunch (will be provided)
12:45 p.m. - Breakout Session #2
1:45 p.m. - Breakout Session #3
2:45 p.m. - Wrap-up/Questions/Drawing
EMC Pre-Compliance Seminars
Ensure your electronic design is EMC compliant
Our experts will walk you through the necessary steps for EMC pre-compliance testing before sending your design off to the test lab. You will receive an overview of EMC standards and the various test instruments, software, and techniques used throughout the process. The presenters will also discuss the potential economic impact of conducting EMC pre-compliance tests or not.
AGENDA (all locations)
8:30 a.m. Registration and Refreshments
9:00 a.m. Seminar and Demos
11:00 a.m. Conclusion
5G/Connected Car Seminar
Tuesday, March 17, 2020
Indiana IoT Lab - Fishers
9059 Technology Lane
Fishers, IN 46038
Automotive safety and connectivity are experiencing a rapid transformation with the advent of vehicle-to-everything (V2X) and 5G. In this seminar, we will discuss the differences between cellular V2X (C-V2X) and dedicated short-range communications (DSRC), the opportunities 5G presents, and the measurement challenges of each.
After presenting a technical overview, this seminar will include three separate breakout sessions with demonstrations:
- Breakout Session #1: Physical Layer and Non-Signaling Measurements (5G/LTE)
- Breakout Session #2: 5G and C-V2X Live Signaling Measurements and Applications Layer Testing
Keysight will also highlight our new 5G/C-V2X Test-as-a-Service (TaaS) offering that is available at our Automotive Customer Center in Novi, MI.
8:30 a.m. Registration
9:00 a.m. Introductions
9:15 a.m. 5G/LTE Basics
- Physical differences
- Network Differences
10:15 a.m. V2X Industry Update
-What is happening in the US and Europe?
11:15 a.m. Break
11:30 a.m. Breakout Session #1
12:30 p.m. Lunch (will be provided)
1:00 p.m. Breakout Session #2
2:00 p.m Break
2:15 p.m. Wrap-Up
Basic RF Measurements Workshop
Hands-on workshop by Keysight and TestEquity
This is an RF measurement course that will discuss the basics of network analyzers, spectrum analyzers, and signal generators. Each attendee will have the opportunity for hands-on measurements using Keysight's FieldFox handheld analyzers. Time is provided for basic questions and to go deeper on certain concepts to better understand the what, how, and why of RF analysis.
AGENDA (all locations)
8:30 a.m. Light Breakfast and Registration
9:00 a.m. Introductions
9:15 a.m. Network Analysis Basics
10:30 a.m. Spectrum Analysis Basics
12:00 p.m. Lunch (will be provided)
1:00 p.m. Cable Loss and Troubleshooting (DTF/TDR)
1:30 p.m. Signal Generator Basics
2:30 p.m. Wrap-up
Streamed from Keysight's Automotive Customer Center in Novi, MI
Feel free to browse these short video clips which highlight specific automotive testing topics and how Keysight can help you in each of these areas.
