A Guide to Signal Integrity Practice from Simulation to Measurement

While data speeds are reaching 400Gbps and beyond, many signal integrity issues are becoming an enormous challenge. Just to name a few: crosstalk, mode conversion, eye closure, insertion loss, and multiple reflections inside the copper channel on backplanes, line cards, ethernet cables, and even connectors.

The digital designer must develop an intuitive insight into the transmission of digital data from the transmitter through the channel interconnects to the receiver.

This brief tutorial video will enable you to get familiar with signal integrity practices.
